Bayan Signage replaces faded, cracked, sagging or out-of-date faces on lightboxes we made and installed across the UAE, from our factory in Ajman. We check the frame against our shop drawing, print the new face on our wide-format printers or cut it from acrylic or polycarbonate, fix any lighting faults while the face is off and refit it.
Lightbox repair usually means replacing the face. A lightbox is a cabinet of aluminium extrusion or folded galvanised steel with lights inside and a translucent face on the front. The cabinet can last fifteen years or more; the face cannot. UV sun yellows acrylic and fades inks, flex stretches and sags, and a stray ball or a shamal gust cracks a panel in seconds. New tenants inheriting a landlord's fascia, brands refreshing their colours and owners whose sign simply looks tired all come to us for the same job: a new face, made to the frame that is already there.
Most of the difference between a good replacement and a poor one happens before printing. Older boxes are rarely square, so we measure the retainer at several points instead of trusting the old artwork file. Acrylic grows in summer heat and needs clearance; flex needs an even tension frame. And a crisp new face exposes uneven lighting that the faded one hid, so we test the LEDs with the face off and fix them before we close the box.
Bayan Signage is the production arm of Bayan Advertising, with 15 years in the UAE, and our factory at Alam Square, Industrial Area 2, Ajman has made lightboxes since 2016. Faces are produced in-house: backlit flex and film on UV and solvent printers up to 3.2 m wide in one pass, acrylic and polycarbonate cut on our CNC routers, and LED modules assembled and tested by our own electricians before the new face goes on.
Trusted by 500+ UAE businesses, including
A lightbox repair often brings related work with it. These are the services and products we combine most, depending on what we find inside the box.
Failed modules, dead drivers and hot spots fixed while the face is off, so you do not pay for access twice to repair the lighting later.
View details →New backlit flex for wide fascias, printed in one piece without a join and re-tensioned in fresh extrusion so it stays flat in heat and wind.
View details →Where the box itself is rusted through or bent, we build a new lightbox fascia in our factory and reuse the power supply and fixing points.
View details →Our full range of backlit boards and lightboxes, for when a rebrand calls for a different shape, depth or lighting style altogether.
View details →Cleaning faces and cabinets, inside and out, to recover brightness on signs whose faces are still sound but dulled by dust.
View details →Scheduled checks for multi-branch brands, so faded or cracked faces are replaced in planned batches rather than one emergency at a time.
View details →We measure the retainer or tension channel at several points, photograph the box by day and night, and note the height and access. Lightbox repair site visits are free in Dubai, Sharjah and Ajman.
Our designers set your Arabic and English artwork to the measured face, then we print a colour sample and view it lit from behind, because brand colours shift once the LEDs are on.
Flex is printed on backlit-grade material up to 3.2 m wide; acrylic and polycarbonate faces are CNC-cut with expansion clearance and finished with translucent vinyl or direct print.
With the old face off, we clean the cabinet, clear drain holes and check for rust, water, dead modules and hot spots. Lighting faults are fixed now, while access is already in place.
Acrylic panels drop into the retainer on spacers that keep the expansion gap. Flex is wrapped into the tension frame and tightened evenly from the centre outwards.
We power the sign and check evenness, colour and light leaks at the edges after dark, remove the old face from site and send before and after photos.
This is our standard for an outdoor shopfront face. We change it for size, height and exposure, and every option is itemised on the quote.
| Component | Our standard | Upgrade options | Why it matters |
|---|---|---|---|
| Face material | 4 to 5 mm opal acrylic outdoors | Backlit flex for wide spans, polycarbonate at low level | Acrylic gives crisp edges; flex runs metres without a join; polycarbonate survives knocks. |
| Graphics | Cast translucent vinyl | Direct UV print, day-night double print | Cast vinyl holds reds and yellows far longer than calendered film in UAE sun. |
| Colour approval | Backlit colour sample | Physical brand sample matched on site | A colour approved under office lights can look pale or shifted once lit. |
| Fitting | About 3 mm clearance per metre, spacers in retainer | New retainers or tension extrusion | A face cut to the exact frame bows or cracks at a fixing in July. |
| Cabinet care | Cleaned out, drain holes cleared | Rust treatment, straightened frame | A clean, drained box keeps the new face clear of dust and condensation. |
| Lighting | Existing LEDs tested and faults fixed | Full LED re-light or fluorescent to LED conversion | Even lighting is what makes a new face look new at night. |
Lightbox repair looks simple, and most problems come from shortcuts. These are the points we explain on almost every job.
Acrylic expands noticeably in heat. Across a summer day a 2 m face can grow by several millimetres, so we allow roughly 3 mm of clearance per metre inside the retainer. A face cut snug to the frame in January bows outwards in July, pops out of its channel or cracks at a screw hole. Clearance is not sloppiness; it is what keeps the panel flat.
Standard acrylic sheet is about 2,440 x 1,220 mm, with larger sheets around 3,050 x 2,030 mm. Beyond that, a face needs a joint, ideally hidden behind a frame divider, or a switch to flex, which we print up to 3.2 m wide in one pass and can run several metres without a seam along its length. A 6 m fascia is almost always flex or segmented acrylic.
Deep reds and navy blues that look right in daylight can wash out to a pale tint once the LEDs are on. We print a backlit sample of your brand colour and, where needed, use day-night printing: a second registered layer behind the face that adds density at night without making the sign look dark by day.
A crisp new face shows dark patches and hot spots more clearly than the faded one it replaces. If modules have failed, are spaced too widely for the box depth, or the box still runs fluorescent tubes, this is the cheapest moment to fix it, because the access is already paid for and the face is already off.
Faces within reach of trolleys, car doors or footballs crack easily, and a hole in July lets dust and insects straight into the box. Polycarbonate costs more than acrylic but survives knocks that would break an acrylic panel outright. We recommend it for any face below about 2.5 m and on forecourts and school sites.
We quote each lightbox repair from the measured frame and your artwork, so there is no fixed price list. Send day and night photos, the rough size and height and your artwork, and you will usually receive an itemised quote within 24 hours.
Larger faces use more material and handling. Polycarbonate costs more than acrylic, oversized acrylic may need joints, and flex is economical over long spans.
Simple cut vinyl lettering is quick. Full-colour prints, gradients, bilingual layouts and day-night printing take more design and print time.
Rust treatment, frame straightening, new drain holes or replacement retainers add work. A sound, clean box keeps the job to the face alone.
Failed LEDs or drivers, or old fluorescent tubes, add parts and labour, though it is cheaper to fix them while the face is already off.
A low fascia needs a ladder or tower; high faces need a boom lift. Night work in malls also affects the installation cost.
A rebrand on an outdoor lightbox can need updated approval drawings, which our draftsmen prepare as part of the job.
A like-for-like replacement of a damaged face with the same graphics often needs no new approval. Changing the brand or trade name on an outdoor lightbox usually means the sign no longer matches its existing permit, so an updated approval from Dubai Municipality, Sharjah or Ajman Municipality, the free-zone authority or the landlord is often needed.
Our technical draftsmen prepare the updated drawings, check that the trade name matches your licence in Arabic and English, and follow the application through. Malls and managed buildings also require work permits for access. Requirements vary by location, so we confirm the current rules for your exact address at the site visit.
Flex and film printed up to 3.2 m wide, and acrylic and polycarbonate cut on our CNC routers, all at our Ajman factory.
We built the box, so we start from our own shop drawing and confirm it on site, and the new face fits the retainers first time.
Our electricians test and repair the LEDs while the face is off, so the lightbox repair is complete and the new face lights evenly from the first night.
When a rebrand needs updated approval, our draftsmen prepare and submit the drawings for the municipality, free zone or landlord.
Face, artwork, lighting work, access and permits are listed separately, and we tell you when a new box makes more sense.
National retail groups, international brands and independent shops return to us for every branch and every rebrand.
It depends on the face size and material, the artwork, the cabinet's condition, any lighting faults and the access needed. A small acrylic face at ground level costs far less than a 7 m flex fascia on a first-floor frontage with LED work. Send photos, size and artwork for an itemised quote, usually within 24 hours.
Yes, in most cases, and it is the most common lightbox repair we do. If the cabinet is sound and the lighting works or can be repaired, a new flex, acrylic or polycarbonate face can be made to fit the existing frame. We inspect the box first and tell you if it is not worth keeping.
Yes. We start from the shop drawing and artwork we hold for your sign, check the frame, cabinet and lighting on site, and quote a face made to fit what is there now. Frames shift slightly over years in the sun, so we always re-measure before cutting. If the frame is damaged, we include repairs or new trims.
Flex suits wide fascias because it runs several metres without joints and is quick to reprint. Acrylic gives a crisper, more premium finish and richer colour, but is limited by sheet size and more brittle. For faces near ground level, polycarbonate is usually the safer choice.
Typically five to eight years before fading becomes obvious, depending on orientation, material and print quality. South and west-facing signs fade fastest. Cast translucent vinyl and UV-protected prints last longer than economy films, and a timer that keeps the sign off by day helps too.
Often, yes, if the brand name or content changes, because the existing permit relates to the old sign. A like-for-like replacement of a damaged face may not need one. Rules vary between Dubai, Sharjah, Ajman and free zones, so we confirm the requirement for your site.
Yes, and it is the best moment, because the face is already off. Old fluorescent tubes and ballasts are removed and replaced with LED modules and a new driver, which usually gives more even light and less heat inside the box. We do this across all seven emirates.
Send your logo, the fascia size and a site photo. Our estimating team replies with options and an itemised price, usually within 24 hours.
