Bayan Signage installs 3D letters on shopfronts, receptions and building facades across the UAE. The crew that fabricates your letters in our Ajman factory sets them out with a full-size template, chooses anchors for the actual wall build-up, routes cables to an accessible driver and tests every letter after dark before handover.
3D letter installation is the last few hours of a job that took weeks to make, and it decides whether the sign sits level, survives a UAE summer and can be serviced later. Letters are fixed on threaded studs, stand-offs, a raceway or a hidden frame, into a wall that might be concrete, render over hollow block, ACP cladding, gypsum, stone or glass. We install for shops, clinics, restaurants, offices and towers, from 100 mm acrylic letters in a lobby to illuminated letters on a facade.
Most installation failures start behind the face. Resin injected into a hollow block runs into the void and leaves a stud with nothing to grip. Studs screwed into 4 mm ACP pull out or dimple the panel. Tape that holds on a cool morning lets go on a west-facing wall in August. A driver sealed behind finished cladding turns a simple replacement into demolition. Our installers drill a test hole before trusting any drawing, and pick the fixing for the wall that is actually there.
Bayan Signage has fabricated and installed letters from its Ajman factory since 2016, and the people who bend and wire your letters are the people who fix them to the wall. That matters on the day: they know which studs carry the load, how each letter is wired and where the drivers were designed to sit. Every set is dry-fitted to its template and checked for studs, cable tails and driver positions in our workshop, so problems are solved on a bench rather than on a ladder.
Trusted by 500+ UAE businesses, including
The mounting method is chosen at the survey from the wall, the letter style and the landlord's rules. These are the ones we use most.
Threaded studs set in resin or anchors chosen for concrete, render or stone. Clean and hidden, with letters close to the wall; the default for most fascias.
View details →Letters held off the wall on locators so light can wash behind them. The gap is set to suit the halo on the drawing, not guessed on site.
View details →Letters pre-wired on a slim colour-matched rail with only a few fixings into the bulkhead. Preferred by many malls and by tenants on shorter leases.
View details →An aluminium or galvanised steel frame tied back to the structure carries the letters, so cladding panels and glass carry no load and stay flat.
View details →Big letters at height fixed to engineered steel frames, installed with boom lifts or rope access and an agreed exclusion zone below.
View details →Flat-cut acrylic, stainless and halo-lit reception letters on gypsum, timber or stone, with backing or cavity fixings rated for the weight.
View details →We measure the zone, identify the substrate, locate power and agree a driver position. Where the build-up is unclear we ask to drill a small test hole. The visit is free in Dubai, Sharjah and Ajman.
Each letter is checked against the approved drawing, studs confirmed straight and tight, cable tails labelled, and a full-size template made from the finished letters rather than the artwork file.
The template is taped up to the agreed datum, checked with a level and string line, measured off fixed features such as columns and door heads, and photographed for your approval before drilling.
Holes are drilled, blown clean and anchored to suit the wall: resin in concrete, mesh-sleeve resin in hollow block, frames behind ACP. Cables are drawn through and labelled to the driver position.
Letters are pushed onto their studs and held while the resin cures, then checked for level, spacing and stand-off. Our electrician connects the drivers in a ventilated box with an isolator.
The sign is tested after dark for even light and dark spots, the wall is cleaned of marks and dust, and you receive photos of the driver and isolator positions for future maintenance.
This is how we fix letters to the walls we meet most often in the UAE. The final choice is made at the survey, once we know what is behind the finish.
| Wall or substrate | Our standard fixing | Upgrade or alternative | Why it matters |
|---|---|---|---|
| Solid concrete | Threaded studs in chemical resin | Stainless expansion anchors | Resin bonds fully into dense concrete and holds without stressing the edges. |
| Render over hollow block | Resin with mesh sleeves | Through-fixed backing rail | Plain resin runs into the void; the sleeve keeps it around the stud. |
| ACP cladding | Hidden aluminium frame tied to structure | Through-bolts with spreader plates for light letters | A 4 mm panel cannot hold studs on its own without pulling out or dimpling. |
| Gypsum partitions | Timber or steel backing behind the board | Rated cavity fixings for light letters | Gypsum crumbles under point loads; backing spreads the weight. |
| Stone cladding | Drilled studs in resin, clear of joints | Fixing through to the wall behind | Stone can crack near edges, and thin veneers may not take a load. |
| Glass and curtain walls | Backing panel or frame on the mullions | Bonded fixings for small indoor letters | The glass itself should carry no load and is rarely drilled. |
| Coastal sites | A4 (316) stainless studs and fixings | Isolating washers between metals | Plated steel rusts and streaks the wall below within a season or two. |
These are the points our crews raise before installation day. Each one is cheap to settle in advance and expensive to fix on a ladder.
Many UAE shopfronts are render over hollow concrete block, and many new units are gypsum or ACP on a frame. Once painted, they look identical. We drill one small test hole in the sign zone before choosing anchors, because resin in a hollow block simply disappears and a stud that feels firm on day one loosens within months. Two minutes with a drill saves a sign that sags in its first summer.
On a long fascia, a baseline 10 mm off level is visible from across the road. Agree with the landlord or consultant exactly where the letters sit: height above finished floor, distance from the bulkhead edge and which feature they centre on. We measure from fixed elements such as columns and door heads as well as the ceiling, because ceilings in fit-outs are rarely level over 6 m.
Drivers need ventilation and an access hatch, ideally within a few metres of the letters. If they end up sealed in a ceiling void or behind cladding, a ten-minute replacement becomes a day of cutting and making good. On a new fit-out, tell your contractor where our drivers go before the bulkhead is boarded, and ask for a hatch big enough to get a hand and a driver through.
High-bond tape looks perfect when the letters go up on a cool morning. On a south or west-facing wall in July, surface temperatures climb far above the air temperature, adhesives soften and letters creep or drop. Outdoors we use mechanical or resin fixings every time, with tape at most as a positioning aid. Indoors, small flat-cut acrylic letters on locating pins and adhesive are fine.
Once letters grow past about a metre, or go above the second floor, wind load and weight matter more than the wall finish. Those letters belong on a galvanised steel frame designed for the load and tied back to the structure, not on studs into cladding. Our draftsmen prepare the frame drawings, and the structural requirements for the fixing are confirmed with your project team or main contractor at the survey stage.
Installation is quoted from the drawing and the survey, together with the letters we fabricate, so one quote covers the sign from factory to wall. You receive an itemised quote that separates labour, access, fixings and electrical work, usually within 24 hours of sending drawings, wall photos and the sign height.
Ladders and towers are simple. Boom lifts, scaffolding or rope access add hire, permits and time, and on towers this can be the largest part of the cost.
Solid concrete is quick to fix into. Hollow block, ACP, stone or glass need sleeves, frames or backing panels, which add materials and labour.
More letters mean more holes, studs and cable routes. Larger letters need more fixings, careful handling and sometimes lifting equipment even at modest heights.
A power point close behind the sign keeps wiring short. Long cable runs, new isolators, conduit or fire-stopped penetrations add electrician time.
Non-lit letters only need fixing. Halo-lit and front-lit letters add driver housings, longer cable routes and a full illumination test on site after fixing.
Mall night shifts, community permits, method statements and the protection of finished floors and facades all affect labour hours and scheduling.
Outdoor letters usually need an approval before they go up: Dubai Municipality, or the free-zone or master-developer authority for the area, in Dubai, and the relevant municipality in Sharjah, Ajman and Abu Dhabi. Malls, communities and building owners add their own NOC, and most ask for insurance and a method statement before any work at height. Indoor reception letters normally need only the landlord's consent.
Our draftsmen prepare the elevation, shop drawing and specification for the submission and check that the trade name matches your licence in Arabic and English. On the day, the crew carries the approval, the NOC and the method statement, and works to the site's safety rules. Requirements vary by location and change over time, so we confirm them for your exact address at the survey.
The crew that fabricates your letters in our Ajman factory installs them, so nothing is lost between the workshop and the wall.
We test the substrate and choose resin, sleeves, frames or backing to suit it, instead of using one anchor for every job.
Our own electricians connect drivers, fit isolators and test every circuit after dark before we hand the finished sign over to you.
Our draftsmen prepare the drawings and submissions for Dubai Municipality, Sharjah and Ajman municipalities, free-zone authorities and landlords before installation day.
Outdoor letters we fabricate and install are covered for 5 years on LEDs, powder coat and structure, with a warranty document at handover.
Our installers are trained for work at height and site safety, from podium steps on a shopfront to boom lifts on a tower.
It depends on height and access, the wall build-up, the number and size of letters, the electrical work and the site's rules. A ground-floor fascia on concrete costs far less than a building name on ACP at 20 m. Send drawings, photos of the wall and the sign height, and we will send an itemised quote, usually within 24 hours.
We give you a realistic installation schedule with the quote, based on access, resin cure times and any mall or building permit windows. Building names at height, large letters on frames and mall night shifts need more site time than a ground-floor shopfront. Fabricating new letters usually takes 5 to 10 working days after approval, and permit time is separate.
Yes. We take the letters down, protect them for transport, check the studs, LEDs and drivers in our workshop and make a new template for the new wall. If the new site needs a different mounting, such as a raceway or frame, we include it in the quote and handle the permit for the new location.
Yes, but the panel alone is rarely strong enough. Small, light letters can be through-bolted with spreader plates behind. Larger letters are fixed to a hidden aluminium or steel frame that ties back through the cladding to the structure, which keeps the panels flat and the fixings secure.
Yes, usually without drilling the glass. Small indoor letters can be bonded with suitable adhesives. Larger or illuminated letters are fixed to a backing panel or frame, or to the mullions of a curtain wall, so the glass carries no load. We confirm the method at the survey.
Usually, yes. Outdoor signs in most emirates need municipality or free-zone approval, and malls and communities often need their own NOC as well. Indoor reception signs normally need only the landlord's approval. We prepare the drawings, handle the submission and confirm the current requirement for your site.
Some marks are unavoidable, because stud holes and cable entries remain. On render they are filled and painted; on cladding they are patched or the panel is replaced. Raceway mounting reduces holes in the wall, which is why some landlords prefer it for rented units. Our sign removal service covers end-of-lease work.
Yes. Our crews install across Dubai, Sharjah, Ajman, Abu Dhabi, Ras Al Khaimah, Umm Al Quwain and Fujairah from our factory in Ajman. The site visit is free in Dubai, Sharjah and Ajman, and multi-branch installations are scheduled so no site is left without a sign.
Send your logo, the fascia size and a site photo. Our estimating team replies with options and an itemised price, usually within 24 hours.
